Product Details:
Payment & Shipping Terms:
|
Usage: | Stencil Cleaner | Industry: | Electronic Industry |
---|---|---|---|
Material: | Metal | Liquid Capacity: | 40L (Max) 20L (Mix) |
Stencil Size: | Max.750 ( W)×750 ( L) X 40 ( H) Mm | Dimensions: | 740 ( W)×100 ( L) X 1785 ( H) Mm |
High Light: | pneumatic cleaner,stencil cleaning machine |
Full Pneumatic Cleaning Machine SMT Stencil Cleaner used in Brazil
Product manual:
● with compressed air as energy, no electricity, there is no fire hazard;
● one-button operation, easy to complete the cleaning, dry work;
● high-density isobaric rotary cleaning nozzle, high cleanliness, steel mesh tension and stability;
● Replaceable modular controller for easy maintenance.
All Unicomp x-ray systems have CE approval.
Unicomp x-ray systems are classified as Cabinet X-Ray Systems and require no external radiation shielding.
Welded steel /Lead/steel construction, no visible lead shielding.
Dimensions |
740 ( W)×100 ( L) x 1785 ( H) mm |
Cleaning method |
Rotary cleaning fluid injection and high pressure air injection |
Stencil Size |
Max.750 ( W)×750 ( L) x 40 ( H) mm(Customized) |
Liquid Capacity |
40L (Max) 20L (Mix) |
Dry Time |
4-6min |
Compressor Air |
0.4-0.6Mpa |
Outlet size |
φ125x30mm ( H ) |
Four Levels Filter System |
First Degree:20μm, second degree: 10μm, Third degree: 5μm, Fourth degree: 1μm |
