Electronics Unicom X-Ray Machine For Defect Detection On Semiconductor Wafer Surfaces

China Electronics Unicom X-Ray Machine For Defect Detection On Semiconductor Wafer Surfaces supplier
Electronics Unicom X-Ray Machine For Defect Detection On Semiconductor Wafer Surfaces supplier

Large Image :  Electronics Unicom X-Ray Machine For Defect Detection On Semiconductor Wafer Surfaces

Product Details:

Place of Origin: China
Brand Name: UNICOMP
Certification: CE, FDA
Model Number: AX8200

Payment & Shipping Terms:

Minimum Order Quantity: 1Set
Price: can negotiate
Packaging Details: Wooden Case, Waterproof, Anti-collision
Delivery Time: 30 days
Payment Terms: T/T, L/C
Supply Ability: 300 sets per month
Contact Now
Detailed Product Description
Name: Unicomp PCB X Ray Machine Application: SMT, EMS,BGA, Electronics, CSP , LED , Flip Chip , Semiconductor
Tube Voltage: 100KV Industry: Electronics Industry
Power: 220AC/50Hz X-ray Leakage: < 1uSv/h

EMS Semiconductor Unicomp PCB X Ray Machine for Electronics BGA AX8200​



X-ray inspection system has been widely applied to Circuit Board Inspection,Semi-Conductor Inspection and Other Applications. (Offline X - Ray series) widely used in offline detection, defect analysis, used for PCBA, packaging, ceramics, plastics, LED, and so on.



The AX-8200 machine is designed to provide high resolution x-ray imaging primarily for the electronics industry. This versatile system is effective for many applications within the PCB manufacturing process. This includes BGA, CSP, QFN, Flip Chip, COB and the wide range of SMT components. The AX-8200 is a powerful support tool for process development, process monitoring and refinement of the rework operation. Supported by a powerful and easy to use software interface, the AX-8200 is capable of addressing small and large volume factory requirements. (Contact us for details)



Applications:



BGA , CSP , LED , Flip Chip , Semiconductor,


Battery Industry , Small Metal Casting,


Electronic Connector Module,


Aerospace Components , Photovoltaic Industry,


Other Special Industries.



OUR SERVICE

1.Your inquiry will be replied in 12 hours.

2.Original Manufacture to customers, with competitive price.

3.We provide one year warranty, free training and whole life technology support.

4.We can arrange the shipment by air, DHL,Fedex, UPS, and by Sea,etc for you, and will give you the tracking NO. after shipment.

5.Well-trained and Professional after-sales service team to support you.

6.Manual will package with machine . It will show you how to use machine step by step.

7.Items are only shipped after payment is received.





Item

Definition

Specs

System Parameters

Size

1080(L)x1180(W)x1730(H)mm

Weight

1150kg

Power

220AC/50Hz

Power Consumption

0.8kW

X-ray Tube

Type

Closed

Max.Voltage

90kV/100kV

Max.Power

8W

Spot Size

5μm

X-ray System

Intensifier

4"Image Intensifier

Monitor

22"LCD

System Magnification

600x

Detection Region

Max.Loading Size

510mm x 420mm

Max.Inspection Area

435mm x 385mm

X-ray Leakage

< 1uSv/h



Inspection Images:

Electronics Unicom X-Ray Machine For Defect Detection On Semiconductor Wafer Surfaces
