Unicomp AX9600 160KV Open Tube 2.5D X-ray for High-Precision TVS Diode Internal
Basic Properties
Place of Origin:
China
Brand Name:
Unicomp
Certification:
CE, FDA
Model Number:
AX9600
Trading Properties
Minimum Order Quantity:
1 set
Price:
On request
Payment Terms:
T/T,L/C
Supply Ability:
500 sets per month
Product Summary
Unicomp High-end Semiconductor X-Ray Inspection System AX9600UNICOMP AX9600 features a self-developed 160kV high-power open micro-focus X-ray tube, delivering an ultra-small 0.8μm focal spot. With exceptional magnification up to 2000 times and outstanding ray penetration capacity, it accurately ...
Product Details
Highlight:
160KV X Ray Baggage Scanner
,32mm Steel X Ray Baggage Scanner
,40AWG Security X Ray Machine
Dimensions:
1655mm(L)×2100mm(W)×1880mm(H)
Tube Type:
Open Type
Machine Weight:
4590KG
Voltage:
160kv
Product Description
Unicomp High-end Semiconductor X-Ray Inspection System AX9600
UNICOMP AX9600 features a self-developed 160kV high-power open micro-focus X-ray tube, delivering an ultra-small 0.8μm focal spot. With exceptional magnification up to 2000 times and outstanding ray penetration capacity, it accurately measures void ratio of TVS diodes, and is ideal for high-precision quality inspection of advanced IC packaging, HBM memory chips and GPU semiconductor components.
Specifications:
| System Summary | Dimensions | 1655mm(L)×2100mm(W)×1880mm(H) |
| Weight | 4590kg | |
| Power Supply | 220V±10% 50Hz/60Hz 9A | |
| Power Consumption | 2kw | |
| X-ray Tube | Tube Type | Open Type |
| Voltage | 160kv | |
| Max.Power | 64W | |
| Focus Spot Size | 1µm | |
| Imaging System | X-ray Detector | FPD |
| Pixel Size | 84µm | |
| Detection Area | 129*129mm | |
| Pixel Matrix | 1536*1536[pixel] | |
| Frame Rates | Max30fps | |
| System Magnification | 34000X | |
| Motion control system | Max. Payload size | 520*520[mm] |
| Max.Detection size | 520*520[mm] | |
| X/Y/Z-Axis Travel Distance(mm) | 550/710/265[mm] | |
| Tilt and Rotation | Detect XY±70° Tilt | |
| Industrial PC | Motion Control Mode | 34"HD 4K curved display |
| Max.Payload Size | Windows 11 64-bit | |
| Max.Detection Size | 4TB HDD+512G SSD | |
| X/Y/Z-axis travel distance(mm) | 32G | |
| Tilt and Rotation | i5 12 generation | |
| Other | Door Open | Automatic Door |
| X-Ray Safety | ＜1µSv/h |
Inspection Images:
Dimensions and Appearance:
