Professional X-Ray Inspection For Electronics Flat Panel Detector FPD 1620 Kg Packing Weight
Basic Properties
Place of Origin:
China
Brand Name:
Unicomp
Certification:
CE, FDA
Model Number:
AX8200MAX
Trading Properties
Minimum Order Quantity:
1 PCS
Price:
can negotiate
Payment Terms:
T/T, L/C
Supply Ability:
300 pcs per month
Product Summary
X-Ray Inspection for Electronics Specification Of SMT X Ray machine System Summary Footprint 1280(W)×1500(D)×1704(H)mm Machine Weight 1450 kg Power Supply AC 110~220V, 50/60Hz Plywood Packing Size 1750(W)×1920(D)×2000(H)cm Packing Weight 1620 kg Power Consumption 1.5 kW X-Ray Tube Tube Type Sealed ...
Product Details
Highlight:
X-Ray Inspection For Electronics
,FPD X Ray Inspection
,Professional X-Ray Inspection
Tube Voltage:
0~90kV (Adjustable)
Tube Type:
Sealed
Focus Spot Size:
5μm
Detector:
Flat Panel Detector (FPD)
Packing Weight:
1620 Kg
Power Supply:
AC 110~220V, 50/60Hz
Product Description
X-Ray Inspection for Electronics
Specification Of SMT X Ray machine
| System Summary | |
| Footprint | 1280(W)×1500(D)×1704(H)mm |
| Machine Weight | 1450 kg |
| Power Supply | AC 110~220V, 50/60Hz |
| Plywood Packing Size | 1750(W)×1920(D)×2000(H)cm |
| Packing Weight | 1620 kg |
| Power Consumption | 1.5 kW |
| X-Ray Tube | |
| Tube Type | Sealed |
| Max. Power | 8W |
| Voltage | 0~90kV (Adjustable) |
| Focus Spot Size | 5μm |
| Imaging System | |
| Detector | Flat Panel Detector (FPD) |
| Pixel Size | 84μm |
| Effective Detection Area | 129*129mm |
| Frame Rates | 30fps |
| Pixel Matrix | 1536*1536 |
| System Magnification | 600X |
| Software | |
| Auto-measuring | BGA Soldering Voids Auto-measuring and Support Data/Graphic Output |
| Multiple Measuring Tools | Support Measuring Distance, Angle, Diameter, Polygon, PTH filling rate, etc. |
| CNC Mode | CNC Programmable Inspection, Easy Operation and User Friendly |
| Real-time Display | Real-time Displaying the Working Data of Voltage, Current, Angle, Date, etc |
| Navigation | Convenient Target Point Positioning System |
| Motion Control System | |
| Movement Control | Joystick, Keypad, Mouse &Touch Panel |
| Max. Loading Area/Weight | 610*610mm / 10kg |
| Max. Inspection Area | 550*550mm |
| Oblique Views | Max. 60°
(X-ray & Detector)
|
| Manipulator | 6-axis with X / Y / Z1 / Z2 / T1 / T2 |
| Industrial PC | |
| Monitor | 24’’ FHD Interactive Touch LCD Display |
| System OS | Windows 10 64bit |
| Hard disk | 1TB |
| RAM | 16GB |
| CPU model | Intel i7 Processor |
| Other Features | |
| Door Open | Electric Sliding |
| X-Ray Safety | <1μSv/h (Meets All International Standards) |
| Authority Management | Fingerprint Access Magnagement System, and Support Password Accessing. |
| Safety Operation | Electromagnetic Interlock, Warning Light and Real-time Radioation Leakage Monitor |
| * Specifications are subject to change without notice, All trademarks are the property of the system maker. | |
Application Fields of X-ray machine
It is extensively utilized in industries such as BGA, CSP, Flip Chip, LED, Fuse, Diode, PCB, Semiconductor, Battery, Small Metal Casting, Electronic Connector Modules, Cables, Aerospace Components, and Photovoltaic, among others.
Function & Features of X-ray machie
Inspection Images of SMT Xray machine
